Quality Tyres,Valued Service!
High-performance Coupé Tire Series
Comfort, high performance, symmetric tread pattern, all-weather support
Comfort: low tire noise, low vibration and impacts against obstacles
High performance: outstanding wear resistance and steering
Symmetric tread pattern: symmetric tread patterns on both sides guarantee excellent high-speed straight running performance
All-weather support: whenever on sunny or rainy days, summer or winter days, the tire always provides good driving and grip force
Supporting data
Features and functions of tread patterns
01 Silent pitch in main tread block
Any cross section in tyre has same size of grooves. It ensures smooth inhale and exhale of air, and reduces tyre noise during driving. The grooves also connect the main tread groove and form a quite environment.
02 Quite-ride pitch arrangement
Optimized pitch width, arrangement and displacement build up a quiet environment for driving and effectively reduce tire resonance.
03 Oblique small grooves in the circumferential strips
The grooves ensure straight running stability and improve acceleration.
04 Specially-processed shoulder tread blocks
Specially-processed steel sheets in the shoulder tread blocks effectively reduce heat generated in the shoulder, and reduce tyre resonance during driving.
05 Four wide longitudinal drainage grooves
Such design ensures good water evacuation performance on wetland, and effectively prevents tyre lateral slip. Reasonably inclined angle could increase longitudinal traction.
06 Shoulder grinding-restraint strip
Grinding-restraint strips around shoulders help stabilize shoulder structure on high speed turning.
Max.Load | |||||||||
SHENGTAI CODE | INCH | SIZE | PATTERN | SPEED | Overall Diameter(MM) | Section Width (MM) | STANDARD RIM | Kg | Kpa |
A114B001 | 13 | 155/65R13 | P309 | 73T | 532 | 157 | 4½J | 365 | 300 |
A228B002 | 13 | 155/70R13 | P309 | 75T | 548 | 157 | 4½J | 387 | 300 |
A229B002 | 13 | 155/80R13 | P309 | 79T | 578 | 157 | 4½J | 437 | 300 |
A110B002 | 13 | 165/65R13 | P309 | 77T | 544 | 170 | 5J | 412 | 300 |
A111B003 | 13 | 165/70R13 | P309 | 79T | 562 | 170 | 5J | 437 | 300 |
A225B002 | 13 | 175/60R13 | P309 | 77T | 540 | 177 | 5J | 412 | 300 |
A112B002 | 13 | 175/65R13 | P309 | 80T | 558 | 177 | 5J | 450 | 300 |
A113B002 | 13 | 175/70R13 | P309 | 82T | 576 | 177 | 5J | 475 | 300 |
A227B002 | 13 | 185/70R13 | P309 | 86T | 590 | 189 | 5½J | 530 | 300 |
A170B004 | 14 | 155/65R14 | P309 | 75T | 558 | 157 | 4½J | 387 | 300 |
A008B002 | 14 | 165/60R14 | P309 | 75H | 554 | 170 | 5J | 387 | 300 |
A007B010 | 14 | 165/70R14 | P309 | 85T | 588 | 170 | 5J | 515 | 340 |
A001B006 | 14 | 175/65R14 | P309 | 82H | 584 | 177 | 5J | 475 | 300 |
A109B003 | 14 | 175/70R14 | P309 | 84H | 602 | 177 | 5J | 500 | 300 |
A109B004 | 14 | 175/70R14 | P309 | 88H | 602 | 177 | 5J | 560 | 340 |
A003B002 | 14 | 185/60R14 | P309 | 82H | 578 | 189 | 5½J | 475 | 300 |
A005B004 | 14 | 185/65R14 | P309 | 86H | 596 | 189 | 5½J | 530 | 300 |
A009B002 | 14 | 185/70R14 | P309 | 88H | 616 | 189 | 5½J | 560 | 300 |
A009B001 | 14 | 185/70R14 | P309 | 88T | 616 | 189 | 5½J | 560 | 300 |
A062B001 | 14 | 195/60R14 | P309 | 86H | 590 | 201 | 6J | 530 | 300 |
A010B003 | 14 | 195/70R14 | P309 | 91T | 630 | 201 | 6J | 615 | 300 |
A215B007 | 14 | 205/70R14 | P309 | 98T | 644 | 209 | 6J | 750 | 340 |
A115B002 | 15 | 175/65R15 | P309 | 84H | 609 | 177 | 5J | 500 | 300 |
A116B004 | 15 | 185/55R15 | P309 | 82V | 585 | 194 | 6J | 475 | 300 |
A117B003 | 15 | 185/60R15 | P309 | 84H | 603 | 189 | 5½J | 500 | 300 |
A117B009 | 15 | 185/60R15 | P309 | 88H | 603 | 189 | 5½J | 560 | 340 |
A011B001 | 15 | 185/65R15 | P309 | 88H | 621 | 189 | 5½J | 560 | 300 |
A015B006 | 15 | 195/60R15 | P309 | 88H | 615 | 201 | 6J | 560 | 300 |
A017B008 | 15 | 195/65R15 | P309 | 91H | 635 | 201 | 6J | 615 | 300 |
A017B009 | 15 | 195/65R15 | P309 | 91V | 635 | 201 | 6J | 615 | 300 |
A019B009 | 15 | 205/60R15 | P309 | 91V | 627 | 209 | 6J | 615 | 300 |
A020B006 | 15 | 205/65R15 | P309 | 94H | 647 | 209 | 6J | 670 | 300 |
A020B007 | 15 | 205/65R15 | P309 | 94V | 647 | 209 | 6J | 670 | 300 |
A118B005 | 15 | 205/70R15 | P309 | 96H | 669 | 209 | 6J | 710 | 300 |
A119B007 | 15 | 215/65R15 | P309 | 96H | 661 | 221 | 6½J | 710 | 300 |
A120B008 | 15 | 215/70R15 | P309 | 98H | 683 | 221 | 6½J | 750 | 300 |
A230B002 | 16 | 185/50R16 | P309 | 85V | 592 | 194 | 6J | 515 | 340 |
A231B002 | 16 | 185/55R16 | P309 | 87V | 610 | 194 | 6J | 545 | 340 |
A125B003 | 16 | 195/60R16 | P309 | 89H | 640 | 201 | 6J | 580 | 300 |
A023B008 | 16 | 205/55R16 | P309 | 91V | 632 | 214 | 6½J | 615 | 300 |
A025B006 | 16 | 205/60R16 | P309 | 92H | 652 | 209 | 6J | 630 | 300 |
A153B002 | 16 | 205/65R16 | P309 | 99H | 672 | 209 | 6J | 775 | 340 |
A027B008 | 16 | 215/60R16 | P309 | 99H | 664 | 221 | 6½J | 775 | 340 |
A322B004 | 16 | 215/60R16 | P309 | 99H | 664 | 221 | 6½J | 775 | 340 |
A030B001 | 16 | 225/50R16 | P309 | 96W | 632 | 233 | 7J | 710 | 340 |
A031B004 | 16 | 225/60R16 | P309 | 98H | 676 | 228 | 6½J | 750 | 300 |
